Q28Y 6*250mm fixed angle notching machine , angle notcher machine

Categories ,
Get A Quote
Facebook Skype

DESCRIPTION

Q28Y 6*250mm fixed angle notching machine , angle notcher machine

video link:

1.Hydraulic under move style,

2.Fixed angle 90, changeable rulers

3.Its welding together by steel plate

4.Single-step or multi-steps choice

5.Lubrication all together

6.The angle is adjustable in chain.

7.Affordable price and high efficiency

8.Big amount and stock

  1. Whole welding structure.
  2. High accuracy and speed.
  3. Less maintain and longer using life.

Video in Youtube:

https://youtu.be/aPoUIZw-Cvk
https://youtu.be/82ochCLkOVw
https://youtu.be/LMJEYpEqaoc



Technical parameters:

No Name 6x250mm 8x300mm 10x300mm
1 Max thickness 0.5-6mm 0.5-8mm 0.5-10mm
If stainless steel 0.5-3mm 0.5-4mm 0.5-5mm
2 Max length 250mm 300mm 300mm
3 Cutting angle 90 90 90
4 Stroke times 35-60/min 30-50/min 25-50/min
5 Worktable height 850mm 900mm 900mm
6 Motor power 4Kw 5.5Kw 5.5Kw
7 Length 910mm 950mm 1020mm
8 Width 810mm 820mm 910mm
9 Height 1050mm 1150mm 1190mm
10 Weight 710Kg 850Kg 1120Kg
