Big hydraulic press brake , Heavy duty press bending machine

  • Specifications:
  • No Model PressureKN BendingLength (mm) ColumnsDistance (mm) OpenHeight (mm) ThroatDepth (mm) SlideStroke (mm) MotorPower (kw) MachineSize (mm)
    1 40T/2500 400 2500 1900 210 200 110 4 2600x1270x1980
    2 63T/2500 630 2500 1900 235 250 120 5.5 2600x1360x2050
    3 63T/3200 630 3200 2600 235 250 120 5.5 3300x1360x2050
    4 80T/2500 800 2500 1900 320 320 150 7.5 2600x1400x2380
    5 80T/3200 800 3200 2600 320 320 150 7.5 3300x1400x2380
    6 80T/4000 800 4000 3100 320 320 150 7.5 4100x1400x2380
    7 100T/2500 1000 2500 1900 330 320 150 7.5 2600x1400x2380
    8 100T/3200 1000 3200 2600 330 320 150 7.5 3300x1400x2380
    9 100T/4000 1000 4000 3100 330 320 150 7.5 4100x1400x2380
    10 100T/5000 1000 5000 4100 330 320 150 7.5 5100x1400x2380
    11 125T/2500 1250 2500 1900 330 320 150 7.5 2600x1400x2380
    12 125T/3200 1250 3200 2600 330 320 150 7.5 3300x1400x2380
    13 125T/4000 1250 4000 3100 330 320 150 7.5 4100x1400x2380
    14 125T/5000 1250 5000 4100 330 320 150 7.5 5100x1400x2380
    15 160T/2500 1600 2500 1900 400 320 200 11 2600x1550x2580
    16 160T/3200 1600 3200 2600 400 320 200 11 3300x1550x2580
    17 160T/4000 1600 4000 3100 400 320 200 11 4100x1550x2580
    18 160T/5000 1600 5000 4100 400 320 200 11 5100x1550x2580
    19 160T/6000 1600 6000 4800 400 320 200 11 6100x1550x2580
    20 200T/2500 2000 2500 1900 435 320 200 15 2600x1650x2900
    21 200T/3200 2000 3200 2600 435 320 200 15 3300x1650x2900
    22 200T/4000 2000 4000 3100 435 320 200 15 4100x1650x2900
    23 200T/5000 2000 5000 4100 435 320 200 15 5100x1650x2900
    24 200T/6000 2000 6000 4800 435 320 200 15 6100x1650x2900
    25 250T/2500 2500 2500 1900 435 320 200 18.5 2600x1750x3070
    26 250T/3200 2500 3200 2600 435 320 200 18.5 3300x1750x3070
    27 250T/4000 2500 4000 3100 435 320 200 18.5 4100x1750x3070
    28 250T/5000 2500 5000 4100 435 320 200 18.5 5100x1750x3070
    29 250T/6000 2500 6000 4800 435 320 200 18.5 6100x1750x3070
    30 300T/3200 3000 3200 2600 435 350 200 22 3300x1850x3285
    31 300T/4000 3000 4000 3100 435 350 200 22 4100x1850x3285
    32 300T/5000 3000 5000 4100 435 350 200 22 5100x1850x3285
    33 300T/6000 3000 6000 4800 435 350 200 22 6100x1850x3285
    34 400T/3200 4000 3200 2600 520 400 250 37 3300x2000x3230
    35 400T/4000 4000 4000 3100 520 400 250 37 4100x2000x3230
    36 400T/5000 4000 5000 4100 520 400 250 37 5100x2000x3230
    37 400T/6000 4000 6000 4800 520 400 250 37 6100x2000x3230
    38 400T/7000 4000 7000 5600 520 400 250 37 7100x2000x3230
    39 500T/4000 5000 4000 3100 600 400 300 45 4100x2400x3710
    40 500T/5000 5000 5000 4100 600 400 300 45 5100x2400x3710
    41 500T/6000 5000 6000 4800 600 400 300 45 6100x2400x3710
    42 500T/7000 5000 7000 5600 600 400 300 45 7100x2400x3710
    43 500T/8000 5000 8000 6200 600 400 300 45 8100x2400x3710
    44 600T/4000 6000 4000 3100 600 400 300 45 4100x2650x3750
    45 600T/5000 6000 5000 4100 600 400 300 45 5100x2650x3750
    46 600T/6000 6000 6000 4800 600 400 300 45 6100x2650x3750
    47 600T/7000 6000 7000 5600 600 400 300 45 7100x2650x3750
    48 600T/8000 6000 8000 6200 600 400 300 45 8100x2650x3750
    49 700T/4000 4000 4000 3100 640 500 300 55 4100x2850x3970
    50 700T/5000 5000 5000 4100 640 500 300 55 5100x2850x3970
    51 700T/6000 6000 6000 4800 640 500 300 55 6100x2850x3970
    52 700T/7000 7000 7000 5600 640 500 300 55 7100x2850x3970
    53 700T/8000 7000 8000 6200 640 500 300 55 8100x2850x3970
    54 800T/4000 8000 4000 3100 800 500 400 2×37 4100x3200x4400
    55 800T/5000 8000 5000 4100 800 500 400 2×37 5100x3200x4400
    56 800T/6000 8000 6000 4800 800 500 400 2×37 6100x3200x4400
    57 800T/7000 8000 7000 5600 800 500 400 2×37 7100x3200x4400
    58 800T/8000 8000 8000 6200 800 500 400 2×37 8100x3200x4400
    59 1000T/5000 10000 5000 4100 800 600 400 2×45 5100x3500x4950
    60 1000T/6000 10000 6000 4800 800 600 400 2×45 6100x3500x4950
    61 1000T/7000 10000 7000 5600 800 600 400 2×45 7100x3500x4950
    62 1000T/8000 10000 8000 6200 800 600 400 2×45 8100x3500x4950
    63 1200T/5000 12000 5000 4100 900 600 400 2×45 5100x3800x5200
    64 1200T/6000 12000 6000 4800 900 600 400 2×45 6100x3800x5200
    65 1200T/7000 12000 7000 5600 900 600 400 2×45 7100x3800x5200
    66 1200T/8000 12000 8000 6200 900 600 400 2×55 8100x3800x5200
